SN16-280-2-858 Horizontal Panning Kitchen Island Series

Heavy-duty, concealed linear slide hardware engineered to smoothly extend kitchen island countertops into floating dining bars and expanded prep surfaces.

The SN16-280-2-858 Series is a premium sliding hardware system designed for modern multi-functional kitchen islands. Installed flush within the cabinet layout, it allows a heavy top slab or countertop surface to glide horizontally or diagonally across the main island base. When extended, it instantly creates comfortable bar seating, extra dining area, or concealed storage access while maintaining rigid stability.

Key Specifications & Configuration Guide

Configuration Type

Small Island (Horizontal)

45∘ Diagonal Island

Hardware Kit Contents

2 Tracks (858 mm)



2 Brackets (280 mm)



2 Load Balance Wheels



4 Noise Limit Stops

2 Tracks (858 mm)



2 Brackets (280 mm)



2 Load Balance Wheels



4 Noise Limit Stops

Movable Top Width

≥ 958 mm

958 mm – 1200 mm

Movable Top Length

< 1200 mm

958 mm – 1200 mm

Max Extension Distance

550 mm

550 mm

Overlap at Max Extension

410 mm

566 mm

Technical Sizing Formula

  • Custom Track Length (X): X = Movable Tabletop Width – 100 mm

Key Highlights

  • Concealed Sliding Design: Installs out of sight beneath the countertop for a clean, floating architectural finish.
  • Heavy-Duty Load Balance: Features industrial load-balancing rollers to prevent tipping or sagging when extended.
  • Whisper-Quiet Motion: Outfitted with specialized noise-reduction limit stops for smooth, silent operation.

Note: Rendered photo for visual representation only. Actual wood grain, texture, and hardware finish may vary slightly on the final product.
